Dolphin M400 IoT parts.
See how it fits.
Explore your cleaner, one assembly at a time. Select a numbered part to find its reference, order from our range or ask our Perth team for help.
Model reference / 99991048-AUIInside your cleaner
Find it in the breakdown.
Choose an assembly, then select a numbered reference. Have your serial number handy to check the right version.
Additional supplied diagrams
Tap a reference to identify a part. Zoom in for detail and drag to move the drawing.
Checking current PRP prices and availability…
Choose a part
Follow the reference.
The part number and available purchase or enquiry options will appear here.
Every listed reference
The M400 IoT parts list.
Model 99991048-AUI. A diagram reference identifies the component; the part number identifies the replacement. Quantity is the number you wish to order.
Browse all 90 part references
| Ref. | Part number / description | Order or enquire |
|---|---|---|
| 9991428-ASSYFilter Cartridge Kit 110M400 IoT | Ask us about this part Enquire about this part | |
| 99957042-ASSYHandle Assy Supreme M4OUTER CASING & HANDLE M400- KIT | Ask us about this part Enquire about this part | |
| 3379720-AScrew KA50X20 (Retail)OUTER CASING CART. M400/500- KIT | Ask us about this part Enquire about this part | |
| 3379720-AScrew KA50X20 (Retail)OUTER CASING & HANDLE M400- KIT | Ask us about this part Enquire about this part | |
| 3379720-AScrew KA50X20 (Retail)Motor Unit Dyn 2010 Ex | Ask us about this part Enquire about this part | |
| 3379440-AScrew KA50X12 A2 WN1412 (Retail)Motor Unit Dyn 2010 Ex | Ask us about this part Enquire about this part | |
| 3389208-AScrew ZP WN1412 KA30X08Motor Unit Dyn 2010 Ex | Ask us about this part Enquire about this part | |
| 3379720-AScrew KA50X20 (Retail)CHASSIS M400/M500 PANEL FINS-KIT | Ask us about this part Enquire about this part | |
| 9995873-DIYCable Dyn 17m SWV DIY (M5)M400 IoT | Ask us about this part Enquire about this part | |
| 9991433-ASSYFilter Panels M500 Fine (Pack of 4)Filter Cartridge Kit 110 | Ask us about this part Enquire about this part | |
| 9980731Filter Cartridge Locking RingFilter Cartridge Kit 110 | Ask us about this part Enquire about this part | |
| 9980753Filter Kit Locking AdaptorFilter Cartridge Kit 110 | Ask us about this part Enquire about this part | |
| 9980733Filter & Cartridge HolderFilter Cartridge Kit 110 | Ask us about this part Enquire about this part | |
| 9980891Non Return ValveFilter Cartridge Kit 110 | Ask us about this part Enquire about this part | |
| 3379440-AScrew KA50X12 A2 WN1412 (Retail)Handle Assy Supreme M4 | Ask us about this part Enquire about this part | |
| M96310025Handle Body 2010 M400 Grey 7544CHandle Assy Supreme M4 | Ask us about this part Enquire about this part | |
| 9991045-ASSYImpeller Cover Supreme M4/5OUTER CASING CART. M400/500- KIT | Ask us about this part Enquire about this part | |
| 9991047-ASSYCartridge Door Kit Supreme 4/5OUTER CASING CART. M400/500- KIT | Ask us about this part Enquire about this part | |
| 99952032-ASSYOuter Casing Supreme M400/M500OUTER CASING CART. M400/500- KIT | Ask us about this part Enquire about this part | |
| 3917031Handle Clip SpringOuter Casing Supreme M400/M500 | Ask us about this part Enquire about this part | |
| 9985065Handle Arm SlideOuter Casing Supreme M400/M500 | Ask us about this part Enquire about this part | |
| 99953054-EXMotor Unit Dyn 2010 ExMOTOR UNIT DYN 2010 – KIT | Ask us about this part Enquire about this part | |
| 99953054-ASSYMotor Unit Dyn 2010 Assy*MOTOR UNIT DYN 2010 – KIT | Ask us about this part Enquire about this part | |
| 9991049-ASSYFloat+House for MU Supreme 5 KitMOTOR UNIT DYN 2010 – KIT | Ask us about this part Enquire about this part | |
| 9995266Impeller + Screw DC BlackMotor Unit Dyn 2010 Ex | Ask us about this part Enquire about this part | |
| 9991044-ASSYIMPELLER CYLINDER+SCREWS ASSYMotor Unit Dyn 2010 Ex | Ask us about this part Enquire about this part | |
| 5588902Impeller Motor Holder 2Motor Unit Dyn 2010 Ex | Ask us about this part Enquire about this part | |
| 9980726MBU Cover Locker Length SideMotor Unit Dyn 2010 Ex | Ask us about this part Enquire about this part | |
| 9980727MBU Cover Locker Short SideMotor Unit Dyn 2010 Ex | Ask us about this part Enquire about this part | |
| 9991217-DIYMBU Cover Diag//DYN 2010Motor Unit Dyn 2010 Ex | Ask us about this part Enquire about this part | |
| 5890051LFCable Loom MBU 2010Motor Unit Dyn 2010 Ex | Ask us about this part Enquire about this part | |
| 3864202Seal 202X4 MBU 2010Motor Unit Dyn 2010 Ex | Ask us about this part Enquire about this part | |
| 3862503Seal Oring 25X3 I.MMotor Unit Dyn 2010 Ex | Ask us about this part Enquire about this part | |
| 5583323Seal Oring 32X3Motor Unit Dyn 2010 Ex | Ask us about this part Enquire about this part | |
| 9991204-ASSYImpeller Motor 2010 ASSYMotor Unit Dyn 2010 Ex | Ask us about this part Enquire about this part | |
| 9995018Electronic Card Dyn 2010 ASSYMotor Unit Dyn 2010 Ex | Ask us about this part Enquire about this part | |
| 5588900Drive Motor HolderMotor Unit Dyn 2010 Ex | Ask us about this part Enquire about this part | |
| 4850010Desiccant Bag*Motor Unit Dyn 2010 Ex | Ask us about this part Enquire about this part | |
| 3862119Seal Oring 2-119 DMMotor Unit Dyn 2010 Ex | Ask us about this part Enquire about this part | |
| 3861902Seal Oring 19X2 DMMotor Unit Dyn 2010 Ex | Ask us about this part Enquire about this part | |
| 9991205-ASSYDrive Motor 2010 ASSYMotor Unit Dyn 2010 Ex | Ask us about this part Enquire about this part | |
| 9980723MBU Box DYN 2010*Motor Unit Dyn 2010 Ex | Ask us about this part Enquire about this part | |
| 9982332Cable Holder DBMotor Unit Dyn 2010 Ex | Ask us about this part Enquire about this part | |
| 3865005Adaptor – Hexagon (D Shaft)CHASSIS M400/M500 PANEL FINS-KIT | Ask us about this part Enquire about this part | |
| 9980883Track for Safety CoverCHASSIS M400/M500 PANEL FINS-KIT | Ask us about this part Enquire about this part | |
| 9980865Side Panel w/Fins Supreme M4CHASSIS M400/M500 PANEL FINS-KIT | Ask us about this part Enquire about this part | |
| 9985006Drive Belt GreyCHASSIS M400/M500 PANEL FINS-KIT | Ask us about this part Enquire about this part | |
| 9980892Brush Safety CoverCHASSIS M400/M500 PANEL FINS-KIT | Ask us about this part Enquire about this part | |
| 3884997Guide WheelCHASSIS M400/M500 PANEL FINS-KIT | Ask us about this part Enquire about this part | |
| 3883645Pulley For Flat Shaft – TTCHASSIS M400/M500 PANEL FINS-KIT | Ask us about this part Enquire about this part | |
| 9991043-ASSYGear For Active Brush AssyCHASSIS M400/M500 PANEL FINS-KIT | Ask us about this part Enquire about this part | |
| 9991046-ASSYDiaphragma 2010 (Pair)CHASSIS M400/M500 PANEL FINS-KIT | Ask us about this part Enquire about this part | |
| 9980890Frame M400/M500*CHASSIS M400/M500 PANEL FINS-KIT | Ask us about this part Enquire about this part | |
| 9991048-ASSYFloats (For Side Panels Kit)CHASSIS M400/M500 PANEL FINS-KIT | Ask us about this part Enquire about this part | |
| 9980922Brush Supporter 2010CHASSIS M400/M500 PANEL FINS-KIT | Ask us about this part Enquire about this part | |
| 9995541-ASSYBrush Active Dyn AssyDRIVE SYS M400/M500 WB- KIT | Ask us about this part Enquire about this part | |
| 9980756Brush Tube Connector DynBrush Active Dyn Assy | Ask us about this part Enquire about this part | |
| 9980736Active BrushBrush Active Dyn Assy | Ask us about this part Enquire about this part | |
| 6101922Brush Support For Active BrushBrush Active Dyn Assy | Ask us about this part Enquire about this part | |
| 9991594Active Brush Holder KitBrush Active Dyn Assy | Ask us about this part Enquire about this part | |
| 99955233-ASSYBrush Assy Dyn WBDRIVE SYS M400/M500 WB- KIT | Ask us about this part Enquire about this part | |
| 99955360-ASSYBrush Assy Dyn WB GreyBrush Assy Dyn WB | Ask us about this part Enquire about this part | |
| 9982275Cork for Inner Wheel TubeBrush Assy Dyn WB | Ask us about this part Enquire about this part | |
| 3884073-ASSYBearing: Wheel Diag BasicBrush Assy Dyn WB | Ask us about this part Enquire about this part | |
| 3885000Stopper Ring DiagBrush Assy Dyn WB | Ask us about this part Enquire about this part | |
| 6101914Diag Basic Inner Wheel TubeBrush Assy Dyn WB | Ask us about this part Enquire about this part | |
| 99955952-ASSYWheel Assy Dyn TTBrush Assy Dyn WB | Ask us about this part Enquire about this part | |
| 58984405LFCable – Power Supply AUPOWER SUPPLY IOT 180W AU – KIT | Ask us about this part Enquire about this part | |
| 9991754Cable LOCKER FOR P.S ASSYPOWER SUPPLY IOT 180W AU – KIT | Ask us about this part Enquire about this part | |
| 99956083AU-AV10Power Supply IoT 180wPOWER SUPPLY IOT 180W AU – KIT | Ask us about this part Enquire about this part | |
| 9991273Retrofit For Cable Con 2010Cable Dyn 1.2m SWV DIY | Ask us about this part Enquire about this part | |
| 9980880Support for Cable 2010Cable Dyn 1.2m SWV DIY | Ask us about this part Enquire about this part | |
| 9995090Cable Float AssyCable Dyn 17m SWV DIY (M5) | Ask us about this part Enquire about this part | |
| 9995791-DIYCable Dyn 1.2m SWV DIYCable Dyn 17m SWV DIY (M5) | Ask us about this part Enquire about this part | |
| 5000009Amphenol Plug*Cable Dyn 17m SWV DIY (M5) | Ask us about this part Enquire about this part | |
| 9991503-ASSYCaddy Sub (Domestic) Screw KitCaddy (Domestic Universal – Retail Carton) | Ask us about this part Enquire about this part | |
| 9980675Caddy Sub (Domestic) Handle HookCaddy (Domestic Universal – Retail Carton) | Ask us about this part Enquire about this part | |
| 9983202Caddy Sub (Domestic NS) Adaptor For PSUCaddy (Domestic Universal – Retail Carton) | Ask us about this part Enquire about this part | |
| 4197023-ASSYCaddy Sub (Domestic) Profile + Insert AssyCaddy (Domestic Universal – Retail Carton) | Ask us about this part Enquire about this part | |
| 9983203Caddy Sub (Domestic NS) Cover for PSU HousingCaddy (Domestic Universal – Retail Carton) | Ask us about this part Enquire about this part | |
| 9983181Caddy Sub (Domestic NS) Adaptor S LineCaddy (Domestic Universal – Retail Carton) | Ask us about this part Enquire about this part | |
| 9980672Caddy Sub (Domestic) Wheel CoverCaddy (Domestic Universal – Retail Carton) | Ask us about this part Enquire about this part | |
| 9980670Caddy Sub (Domestic) BaseCaddy (Domestic Universal – Retail Carton) | Ask us about this part Enquire about this part | |
| 9980681Caddy Sub (Domestic) WheelCaddy (Domestic Universal – Retail Carton) | Ask us about this part Enquire about this part | |
| 9996085-ASSYCaddy (Domestic Universal – Retail Carton)CADDY S2 COLOR – KIT | Ask us about this part Enquire about this part | |
| 1811404Cable ConnectorRetrofit For Cable Con 2010 | Ask us about this part Enquire about this part | |
| 3861002RK RING FOR CABLE CONN.Retrofit For Cable Con 2010 | Ask us about this part Enquire about this part | |
| 9980025Washer Gland 13MMRetrofit For Cable Con 2010 | Ask us about this part Enquire about this part | |
| 9985027PLASTIC WASHER 7MM X 2MMRetrofit For Cable Con 2010 | Ask us about this part Enquire about this part | |
| 9985048Cable Conn Three PinRetrofit For Cable Con 2010 | Ask us about this part Enquire about this part |
