PRP / Maytronics spare parts
Dolphin Wave 75 parts.
See how it fits.
Explore your cleaner, one assembly at a time. Select a numbered part to find its reference, order from our range or ask our Perth team for help.
Model reference / 99996942-AUInside your cleaner
Find it in the breakdown.
Use the numbered drawing and select the matching reference from the parts list. Have your serial number handy to check the right version.
Select a reference from the parts list to identify the numbered component. Zoom in for detail and drag to move the drawing.
Checking current PRP prices and availability…
Choose a part
Follow the reference.
The part number and available purchase or enquiry options will appear here.
Every listed reference
The Wave 75 parts list.
Model 99996942-AU. A diagram reference identifies the component; the part number identifies the replacement. Quantity is the number you wish to order.
Browse all 119 part references
| Ref. | Part number / description | Order or enquire |
|---|---|---|
| 9991838Chassis Wave 75*Wave 75 | Ask us about this part Enquire about this part | |
| 9995671-AU-15Power Supply Dyn 2010 AUACCESSORIES | Ask us about this part Enquire about this part | |
| 5020012Socket Cover For PSUPower Supply Dyn 2010 AU | Ask us about this part Enquire about this part | |
| 5020011Amph. Socket For PsPower Supply Dyn 2010 AU | Ask us about this part Enquire about this part | |
| 58984405LFCable – Power Supply AUPower Supply Dyn 2010 AU | Ask us about this part Enquire about this part | |
| 5898426LFCable – Power Supply TH (*)Power Supply Dyn 2010 AU | Ask us about this part Enquire about this part | |
| 3379212Screw KA30X12Power Supply Dyn 2010 AU | Ask us about this part Enquire about this part | |
| 99954226-ASSYRCU DYN 2010ACCESSORIES | Ask us about this part Enquire about this part | |
| 9996098-ASSYCaddy (2011)ACCESSORIES | Ask us about this part Enquire about this part | |
| 9991098Caddy Sub (Domestic) Top HandleCaddy (2011) | Ask us about this part Enquire about this part | |
| 9980675Caddy Sub (Domestic) Handle HookCaddy (2011) | Ask us about this part Enquire about this part | |
| 9980679Caddy Sub (Domestic 2011) RC HolderCaddy (2011) | Ask us about this part Enquire about this part | |
| 9980676Caddy Sub (Domestic) Profile InsertCaddy (2011) | Ask us about this part Enquire about this part | |
| 9991503-ASSYCaddy Sub (Domestic) Screw KitCaddy (2011) | Ask us about this part Enquire about this part | |
| 9980678Caddy Sub (Demestic 2011) Cable HolderCaddy (2011) | Ask us about this part Enquire about this part | |
| 4197023-ASSYCaddy Sub (Domestic) Profile + Insert AssyCaddy (2011) | Ask us about this part Enquire about this part | |
| 4197024-ASSYCaddy Sub (Domestic 2011) Profile Al+Insert AssyCaddy (2011) | Ask us about this part Enquire about this part | |
| 9980681Caddy Sub (Domestic) WheelCaddy (2011) | Ask us about this part Enquire about this part | |
| 9980672Caddy Sub (Domestic) Wheel CoverCaddy (2011) | Ask us about this part Enquire about this part | |
| 9980670Caddy Sub (Domestic) BaseCaddy (2011) | Ask us about this part Enquire about this part | |
| 9980220Non Return Diafram DiagWave 75 | Ask us about this part Enquire about this part | |
| 9985448Cartridge CorkWave 75 | Ask us about this part Enquire about this part | |
| 9995369RD-EXMotor Unit Dyn Wagon 3H ExMOTOR UNIT | Ask us about this part Enquire about this part | |
| 9995266Impeller + Screw DC BlackWave 75 | Ask us about this part Enquire about this part | |
| 3884997Guide WheelWave 75 | Ask us about this part Enquire about this part | |
| 3883645Pulley For Flat Shaft – TTWave 75 | Ask us about this part Enquire about this part | |
| 9985006Drive Belt GreyWave 75 | Ask us about this part Enquire about this part | |
| 3865005Adaptor – Hexagon (D Shaft)Wave 75 | Ask us about this part Enquire about this part | |
| 99806415Side Panel W75*Wave 75 | Ask us about this part Enquire about this part | |
| 99806211Side Cover W75 C.Grey 11C*Wave 75 | Ask us about this part Enquire about this part | |
| 99955956-ASSYWheel Assy For Timing Track Dyn DBWave 75 | Ask us about this part Enquire about this part | |
| 9982275Cork for Inner Wheel TubeWheel Assy For Timing Track Dyn DB | Ask us about this part Enquire about this part | |
| 3884073-ASSYBearing: Wheel Diag BasicWheel Assy For Timing Track Dyn DB | Ask us about this part Enquire about this part | |
| 3885000Stopper Ring DiagWheel Assy For Timing Track Dyn DB | Ask us about this part Enquire about this part | |
| 6101924Wheel Tube for Dyn TT Wheel AssyWheel Assy For Timing Track Dyn DB | Ask us about this part Enquire about this part | |
| 6101914Diag Basic Inner Wheel TubeWheel Assy For Timing Track Dyn DB | Ask us about this part Enquire about this part | |
| 6250945Float MTC5 Wave 75Wave 75 | Ask us about this part Enquire about this part | |
| 9995876-DIYCable Dyn Basic 24m SWV DIYCABLE ASSY DYN BAS 24M’ -CATALOG | Ask us about this part Enquire about this part | |
| 9995090Cable Float AssyCable Dyn Basic 24m SWV DIY | Ask us about this part Enquire about this part | |
| 9995791-RC-DIYCable Dyn 1.2m SWV DIY (Wave 75)Cable Dyn Basic 24m SWV DIY | Ask us about this part Enquire about this part | |
| 9991279Retrofit For Cable Con 3 PinCable Dyn 1.2m SWV DIY (Wave 75) | Ask us about this part Enquire about this part | |
| 1811404Cable ConnectorRetrofit For Cable Con 3 Pin | Ask us about this part Enquire about this part | |
| 3861002RK RING FOR CABLE CONN.Retrofit For Cable Con 3 Pin | Ask us about this part Enquire about this part | |
| 9980025Washer Gland 13MMRetrofit For Cable Con 3 Pin | Ask us about this part Enquire about this part | |
| 9980041Bolt – Motor Unit Cable ConnectorRetrofit For Cable Con 3 Pin | Ask us about this part Enquire about this part | |
| 9985027PLASTIC WASHER 7MM X 2MMRetrofit For Cable Con 3 Pin | Ask us about this part Enquire about this part | |
| 9985048Cable Conn Three PinRetrofit For Cable Con 3 Pin | Ask us about this part Enquire about this part | |
| 3917033Cable Spring DynCable Dyn 1.2m SWV DIY (Wave 75) | Ask us about this part Enquire about this part | |
| 5000009Amphenol Plug*Cable Dyn Basic 24m SWV DIY | Ask us about this part Enquire about this part | |
| 99960081Float Assy D.Basic Float BlueCable Dyn Basic 24m SWV DIY | Ask us about this part Enquire about this part | |
| 9982263Cover – Cable Float Blue (DB, S100)*Float Assy D.Basic Float Blue | Ask us about this part Enquire about this part | |
| 6250930Polystyrene FloatFloat Assy D.Basic Float Blue | Ask us about this part Enquire about this part | |
| 9995791-RC-DIYCable Dyn 1.2m SWV DIY (Wave 75)CABLE ASSY DYN BAS 24M’ -CATALOG | Ask us about this part Enquire about this part | |
| 9991279Retrofit For Cable Con 3 PinCable Dyn 1.2m SWV DIY (Wave 75) | Ask us about this part Enquire about this part | |
| 1811404Cable ConnectorRetrofit For Cable Con 3 Pin | Ask us about this part Enquire about this part | |
| 3861002RK RING FOR CABLE CONN.Retrofit For Cable Con 3 Pin | Ask us about this part Enquire about this part | |
| 9980025Washer Gland 13MMRetrofit For Cable Con 3 Pin | Ask us about this part Enquire about this part | |
| 9980041Bolt – Motor Unit Cable ConnectorRetrofit For Cable Con 3 Pin | Ask us about this part Enquire about this part | |
| 9985027PLASTIC WASHER 7MM X 2MMRetrofit For Cable Con 3 Pin | Ask us about this part Enquire about this part | |
| 9985048Cable Conn Three PinRetrofit For Cable Con 3 Pin | Ask us about this part Enquire about this part | |
| 3917033Cable Spring DynCable Dyn 1.2m SWV DIY (Wave 75) | Ask us about this part Enquire about this part | |
| 9991279Retrofit For Cable Con 3 PinWave 75 | Ask us about this part Enquire about this part | |
| 1811404Cable ConnectorRetrofit For Cable Con 3 Pin | Ask us about this part Enquire about this part | |
| 3861002RK RING FOR CABLE CONN.Retrofit For Cable Con 3 Pin | Ask us about this part Enquire about this part | |
| 9980025Washer Gland 13MMRetrofit For Cable Con 3 Pin | Ask us about this part Enquire about this part | |
| 9980041Bolt – Motor Unit Cable ConnectorRetrofit For Cable Con 3 Pin | Ask us about this part Enquire about this part | |
| 9985027PLASTIC WASHER 7MM X 2MMRetrofit For Cable Con 3 Pin | Ask us about this part Enquire about this part | |
| 9985048Cable Conn Three PinRetrofit For Cable Con 3 Pin | Ask us about this part Enquire about this part | |
| 5000009Amphenol Plug*Wave 75 | Ask us about this part Enquire about this part | |
| 9982332Cable Holder DBWave 75 | Ask us about this part Enquire about this part | |
| 3917033Cable Spring DynWave 75 | Ask us about this part Enquire about this part | |
| 99951916Outer Casing Wave 75Wave 75 | Ask us about this part Enquire about this part | |
| 3379720-AScrew KA50X20 (Retail)Outer Casing Wave 75 | Ask us about this part Enquire about this part | |
| M96700232Top ShellOuter Casing Wave 75 | Ask us about this part Enquire about this part | |
| M96700046Handle Holder MCC5 OrangeOuter Casing Wave 75 | Ask us about this part Enquire about this part | |
| 9980633Handle Adaptor – TridentOuter Casing Wave 75 | Ask us about this part Enquire about this part | |
| M96700005Impeller Cover MMC5 Orange (137C)Wave 75 | Ask us about this part Enquire about this part | |
| 99954305-ASSYFilter Bag 70M (Pack of 5)Wave 75 | Ask us about this part Enquire about this part | |
| 99957074-ASSYHandle Assy Wave 75Wave 75 | Ask us about this part Enquire about this part | |
| 6250941Float for Dyn DJWave 75 | Ask us about this part Enquire about this part | |
| 6101635Brush Dyn PVC Grey*BRUSHES- DYN GREY | Ask us about this part Enquire about this part | |
| 61020801Brush Dyn PVC Grey (Moulded)*BRUSHES- DYN GREY | Ask us about this part Enquire about this part | |
| 6101656Brush Dyn CB Grey*BRUSHES- DYN GREY | Ask us about this part Enquire about this part | |
| 61020601Brush Dyn CB Grey (Moulded)*BRUSHES- DYN GREY | Ask us about this part Enquire about this part | |
| 6101611Brush WB RingBRUSHES- DYN GREY | Ask us about this part Enquire about this part | |
| 9995560-ASSYBrush WB Dyn PairBRUSHES- DYN GREY | Ask us about this part Enquire about this part | |
| 99955340-ASSYWheel Assy Dyn CB GreyBRUSHES- DYN GREY | Ask us about this part Enquire about this part | |
| 6101611Brush WB RingWheel Assy Dyn CB Grey | Ask us about this part Enquire about this part | |
| 61020601Brush Dyn CB Grey (Moulded)*Wheel Assy Dyn CB Grey | Ask us about this part Enquire about this part | |
| 9982275Cork for Inner Wheel TubeWheel Assy Dyn CB Grey | Ask us about this part Enquire about this part | |
| 3884073-ASSYBearing: Wheel Diag BasicWheel Assy Dyn CB Grey | Ask us about this part Enquire about this part | |
| 3885000Stopper Ring DiagWheel Assy Dyn CB Grey | Ask us about this part Enquire about this part | |
| 6101914Diag Basic Inner Wheel TubeWheel Assy Dyn CB Grey | Ask us about this part Enquire about this part | |
| 99955360-ASSYBrush Assy Dyn WB GreyBRUSHES- DYN GREY | Ask us about this part Enquire about this part | |
| 9980640Brush Support Deluxe 5Wave 75 | Ask us about this part Enquire about this part | |
| 9991414-ASSYFilter Cartridge Assy For MTC5/6 MCC5Wave 75 | Ask us about this part Enquire about this part | |
| 9991425-ASSYFilter Cartridge Kit Pleated (4 Pack)Filter Cartridge Assy For MTC5/6 MCC5 | Ask us about this part Enquire about this part | |
| 9982271Bottom Lid DB CartridgeFilter Cartridge Assy For MTC5/6 MCC5 | Ask us about this part Enquire about this part | |
| 9980119Filter Cartridge Holder Dyn*Filter Cartridge Assy For MTC5/6 MCC5 | Ask us about this part Enquire about this part | |
| 9985439Non Return Flap For CartridgeFilter Cartridge Assy For MTC5/6 MCC5 | Ask us about this part Enquire about this part | |
| 3917014Bottom Lid SpringFilter Cartridge Assy For MTC5/6 MCC5 | Ask us about this part Enquire about this part | |
| 9985447Base for Cartridge Non Return Flap*Filter Cartridge Assy For MTC5/6 MCC5 | Ask us about this part Enquire about this part | |
| 9985446Hook Lock For CartridgeFilter Cartridge Assy For MTC5/6 MCC5 | Ask us about this part Enquire about this part | |
| 9982330Filter Cover Latch DBFilter Cartridge Assy For MTC5/6 MCC5 | Ask us about this part Enquire about this part | |
| 9982331Bottom Lid Spring DBFilter Cartridge Assy For MTC5/6 MCC5 | Ask us about this part Enquire about this part | |
| 9980627Net MCC5Wave 75 | Ask us about this part Enquire about this part | |
| 99919117Bottom Lid DB & Support AssyWave 75 | Ask us about this part Enquire about this part | |
| 3303008-AScrew KA30X8 WN1412 A2Bottom Lid DB & Support Assy | Ask us about this part Enquire about this part | |
| 5583077Filter Bag Support DJBottom Lid DB & Support Assy | Ask us about this part Enquire about this part | |
| 9982270Bottom Lid DiagBottom Lid DB & Support Assy | Ask us about this part Enquire about this part | |
| 9982330Filter Cover Latch DBBottom Lid DB & Support Assy | Ask us about this part Enquire about this part | |
| 9982331Bottom Lid Spring DBBottom Lid DB & Support Assy | Ask us about this part Enquire about this part | |
| 9985441Non return flap for new blBottom Lid DB & Support Assy | Ask us about this part Enquire about this part | |
| 9985442Non return Flap Base Kit (Wave)*Bottom Lid DB & Support Assy | Ask us about this part Enquire about this part | |
| 3917014Bottom Lid SpringBottom Lid DB & Support Assy | Ask us about this part Enquire about this part | |
| 3379720-AScrew KA50X20 (Retail)Wave 75 | Ask us about this part Enquire about this part | |
| 3379440-AScrew KA50X12 A2 WN1412 (Retail)Wave 75 | Ask us about this part Enquire about this part | |
| 3305030-AScrew KA50X30 (Retail)Wave 75 | Ask us about this part Enquire about this part | |
| 3379440-AScrew KA50X12 A2 WN1412 (Retail)Wave 75 | Ask us about this part Enquire about this part |
Local matching help
Not sure which version?
Send your cleaner model, serial number and a photo of the part. Our Wangara and Jandakot team can help you find the right match.
